Product Description
Balboa AX40 4-Button Auxiliary Topside Control Panel (Jets 1–4 Configuration)
FREE UPS Ground Shipping, UPS 2-Day Add $44.99
Description
The Balboa 34-55487-K AX40 Auxiliary Topside Control Panel is a spa-side secondary control designed for Balboa 8000-series spa systems. It provides direct control of all four jet functions from a remote spa-side location, allowing independent pump activation depending on spa configuration.
This is a non-display auxiliary keypad used alongside a primary topside control such as TP or VL series panels.
Key Features
- OEM Balboa AX40 auxiliary control panel
- 4-button independent jet control (Jets 1–4)
- No LCD display (auxiliary function only)
- Spa-side waterproof construction
- 6-pin Molex connection interface
- Designed for Balboa 8000-series systems
- Durable UV- and moisture-resistant housing
- Replaceable overlay label system
- Supports multi-pump spa configurations
- Common retrofit and OEM replacement part
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Balboa Water Group |
| MPN | 34-55487-K |
| Base Part | 55487 |
| Model | AX40 Auxiliary |
| Button Count | 4 |
| Button Layout | Jets 1 / Jets 2 / Jets 3 / Jets 4 |
| Display | None |
| Connector | 6-Pin Molex |
| Cable Length | ~18 ft |
| Series | AX40 / 8000 Series |
| Application | Spa / Hot Tub |
| Condition | New |
