Product Description
Balboa TP600 6-Button LCD Spa Topside Control Panel
FREE UPS Ground Shipping, UPS 2-Day Add $44.99
Description
The Balboa 34-50056-K TP600 Spa Topside Control Panel is a full-function spa-side interface used in Balboa BP-series spa systems. It provides complete control of spa functions including jets, lighting, auxiliary modes, temperature adjustment, and system navigation depending on overlay configuration.
This is one of the most widely used Balboa keypads due to its reliability, compatibility, and multi-function control layout.
Key Features
- OEM Balboa TP600 spa control panel
- 6-button multifunction spa interface
- LCD display shows temperature and system status
- Compatible with Balboa BP-series spa systems
- Controls jets, flip mode, light, warm, and cool functions
- 4-pin Molex waterproof connector
- Durable outdoor-rated spa housing
- Includes overlay (80-12198 configuration common)
- Widely used OEM replacement keypad
- Supports multi-pump spa configurations
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Balboa Water Group |
| MPN | 34-50056-K |
| Base Part | 50056 |
| Model | TP600 |
| Buttons | 6 |
| Button Layout | J/J/F/W/L/C |
| Display | LCD |
| Connector | 4-Pin Molex |
| Cable Length | ~7 ft |
| Panel Size | 7.1" x 3.5" |
| Series | TP / BP Series |
| Application | Spa / Hot Tub |
| Condition | New |
