Product Description
1.5 HP Waterway E-Series Spa Pump
2 Speed 115V 3420610-15
303479, 403479 Dream Maker Replacement
FREE SHIPPING, 303479
| Complete Pump Type | Portable Spa Pump |
| Speed | 2 Speed (2-Spd) |
| Motor Voltage | 115v |
| Drain Plug Location | 3,6,9 o`clock |
| Pump to Motor Foot Types | 15 |
| Suction Style | Center |
| Suction Connection (Physical Dimension) | 1-11/16"id, 2-7/16"od |
| Suction Connection Type | Female Pipe Thread (fpt), Male Buttress Thread (mbt) |
| Suction Pipe Size | 1-1/2" |
| Discharge Style | Center |
| Discharge Connection (Physical Dimension) | 1-11/16"id, 2-7/16"od |
| Discharge Connection Type | Female Pipe Thread (fpt), Male Buttress Thread (mbt) |
| Discharge Pipe Size | 1-1/2" |
| Horsepower | 1.5 hp |
| Motor Frame | 48 Frame Thru-Bolt |
| Motor Amperage/Wattage | 13.3A/4.1A |
| Manufacturer | Waterway |
| Pump Model | E-Series Center Discharge |
| Manufacturer Impeller Number | 310-8030 |
| Volute Fastening Type | 6 Screws |
| Volute/Sealplate Number | 315-1070 |
| Manufacturer Wet End Number | 310-1140 |
