Product Description
Balboa VS510SZ Circuit Board 33-54372-K
Balboa VS510SZ Tech & Info Sheet
Description
SKU: 54372
MPN: 54372-02
Model: VS510SZ
UPC: 682698983423
Manufacturer: Balboa Water Group®
Warranty: 1 yr. with manufacturer
Balboa® VS510SZ Circuit Board M7 Technology
*All circuit boards will require correct board voltage install and component voltage set-up by moving the component wires on the board, in addition to setting dipswitches correctly. Some configuration on the topside may also be required. Please reference the wiring schematics*
Features:
- Does not require a pressure switch or external sensors.
- Used (2) Chip numbers VS510SZR1(x)/ VS510SZR2 / VS510SR1(x)
Product specifications:
- 8 Pin Phone Cable
Compatible with: The following topside control panels 51057 -5318
Replaces: 055036, 33-0033, 54357, 54372, 54372-01, 54372-03, 55099, HS200M7, HS200VSR2B, KEYS211DR1B, VS510SR2B, VS510SZR1A, VS510SZR2, 33-0033-K
Alternates: 3-60-0079, 55099-01, 55098, 54372-03 (Balboa), 59-138-1684
Documents:
- PDF 54372 Hot sheet
- VS510SZ Tech Sheet
