Balboa AX40 4-Button Auxiliary Topside Control Panel
FREE UPS Ground Shipping, UPS 2-Day Add $44.99
Description
The Balboa 34-52678-K AX40 Auxiliary Topside Control Panel is a spa-side secondary control interface used in Balboa 8000-series spa systems. It provides direct control of spa functions such as jets, blower, and lighting from a remote spa-side location.
This is a non-display auxiliary keypad, meaning it operates in conjunction with a primary topside control (such as TP series panels) and communicates with the spa pack via a 6-pin Molex connection.
Key Features
- OEM Balboa AX40 auxiliary control panel
- 4-button spa-side operation
- Controls jets, blower, and lighting functions
- No LCD display (auxiliary function panel)
- 6-pin Molex spa harness connection
- Designed for 8000-series spa systems
- Durable waterproof spa-rated construction
- Replacement for failed auxiliary keypads
- Includes face overlay (configuration dependent)
- Flush-mount spa-side installation
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Balboa Water Group |
| MPN | 34-52678-K |
| Base Part | 52678 |
| Model | AX40 |
| Button Count | 4 |
| Button Layout | Jets / Jets / Blower / Light (varies) |
| Display | None |
| Connector | 6-Pin Molex |
| Cable Length | ~18 ft |
| Series | AX / 8000 Series |
| Application | Spa / Hot Tub |
| Condition | New |
Compatibility
Compatible with many Balboa BP control systems including:
- BP501
- BP7
- BP2000
- BP2100
Always verify software and topside compatibility before ordering.
