Product Description
Waterway Hi-Flo Pump
Complete Wet End, .75-HP to 4-HP
FREE SHIPPING
Waterway BaquaPure/Hi-Flo Complete Wet End - (.75-HP - 4HP)
The complete wet end includes: the volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring and suction cover screws
.75HP 310-1120SD
1 HP 310-1130SD
1.5 HP 310-1140SD
2 HP 310-1141SD
3 HP 310-1150SD
4 HP 310-1160SD
| Pump to Motor Foot Types | 17 |
| Motor Frame | 48 Frame Thru-Bolt |
| Drain Plug Location | 3,6,9 o`clock |
| Suction Auxillary Port | None |
| Suction Style | Center |
| Suction Connection (Physical Dimension) | 3-1/16"od |
| Suction Connection Type | Male Buttress Thread (mbt) |
| Suction Pipe Size | 2" |
| Discharge Auxilary Port | None |
| Discharge Style | Side |
| Discharge Connection (Physical Dimension) | 1-3/4"id, 3-1/16"od |
| Discharge Connection Type | Female Pipe Thread (fpt), Male Buttress Thread (mbt) |
| Discharge Pipe Size | 2" |
| Horsepower | Varies |
| Manufacturer | Waterway |
| Pump Model | Hi-Flo |
| Manufacturer Impeller Number | Varies |
| Volute Fastening Type | 8 Screws |
| Volute/Seal plate Part Number | 315-2500 |
